artnovion

Helen CS

Home Cinema and Media Room (Cinema Series)
Helen CS is an acoustic panel with a neutral design that creates the right atmosphere in any space.
Size available
  • 595 x 595 x 16mm

Helen CS is part of the Cinema Series (CS): A modular system with four different core options: an Absorber, a Diffuser, a Bass Trap and a Frame core.

finishes
Suede | Anthracite Grey
Suede | Ink Black
Suede | Ash Grey
Weave | Black

Helen CS is an acoustic panel with a neutral design and impressive absorption that creates the right atmosphere in any space with a discreet modular installation system.

This modular system uses four different wooden cores: an Absorber, Diffuser, Bass Trap, and Frame options. Each provides distinct functionality while keeping the same design. The acoustic covers can be easily swapped or replaced.

Absorbers remove energy from incoming sound waves, reducing reflections and overall reverberation time. Diffusers scatter energy over a wide area, creating more homogenous sound fields. Bass Traps reduce low frequency room modes, diminishing the effect of standing waves. Frame cores seamlessly integrate in-wall speakers.

Type

Helen CS + Absorber Core
Absorption range: 500 Hz to 5000 Hz
Acoustic class: C | (aw) = 0.75

______

Helen CS + Bass Trap Core
Absorption range: 100 Hz to 125 Hz

______

Helen CS + Diffuser Core
Scattering range: 1000 Hz to 8000 Hz

Purpose

  • First reflection control
  • RT reduction
  • Flutter echo control
  • Reducing excessive reverberation
  • Improving speech intelligibility

Recommended for

  • Home cinemas
  • Media rooms

Dimensions
595 x 595 x 16mm | 0.75 Kg
